DESCRIPTION
This compact CWDM multiplexer/demultiplexer covers all 18 CWDM channels. The form factor makes is very applicable for use in fiber optic splicing enclosures.

FEATURES
- Coarse WDM in compliance with ITU-T G.694.2
- Standard 18 CWDM channels 1270 – 1610nm
- Package Dimension (mm: L44 x W28 x H6mm)
- Tolerance is 6.2+/-0.2mm
- 1,5m bare fibers, 250µm/900µm
- 1,5m LC/UPC, 250µm/900µm
- Channel Spacing (nm): 20
- Insertion Loss Channels (dB): 3.0
- Polarization Dependent Loss (dB): 0.2
- Polarization Mode Dispersion (ps): 0.1
- Directivity (dB): 50
- Return Loss (dB): 45
- Maximum Power Handling (mW): 500
- Operating temperature: -30 ~ +70°C
- Storage temperature: -40 ~ +80°C
