Key Features
Supports up to 10.7Gbps bit rates
Hot-pluggable SFP+ footprint
1270nm DFB laser and PIN photodiode, Up to 20km for SMF transmission
Compliant with SFP+ MSA and SFF-8472 with simplex LC receptacle
Compatible with RoHS
Single +3.3V power supply
Transmitter Type: 1270nm DFB
Receiver Type: PIN
Real Time Digital Diagnostic Monitoring
Operating case temperature:
Standard: 0 to +70°C
TX Power: -5~0dBm
Receiver Sensitivity: < -14dBm
Application
10Gbps Optical systems
10GBASE-LR at 10.3125Gbps
10GBASE-LW at 9.953Gbps
LTE systems
