SFP BIDI  1GE  DDM  SM  20km TX/RX=1310/1550nm  14dB  SC SFP BIDI  1GE  DDM  SM  20km TX/RX=1310/1550nm  14dB  SC

SFP BIDI 1GE DDM SM 20km

TX/RX=1310/1550nm 14dB SC

Varenr:S1G-BX20SC-35
Teknisk info
Teknisk info
Key Features
Dual data-rate of 1.25Gbps/1.063Gbps operation
1310nm FP laser and PIN photodetector for 20km transmission
Compliant with SFP MSA and SFF-8472 with simplex SC receptacle
Digital Diagnostic Monitoring:Internal Calibration or External Calibration
Compatible with SONET OC-24-LR-1
Compatible with RoHS
+3.3V single power supply
Operating case temperature:
Standard: 0 to +70°C
TX Power: -9.0~0dBm
Receiver Sensitivity: <-23.0dBm
Powerbudget: 14dB


Application
Gigabit Ethernet
Fiber Channel
Switch to Switch interface
Switched backplane applications
Router/Server interface
Other optical transmission systems
