Key Features
Supports up to 25.78Gbps bit rates
Hot-pluggable SFP+ footprint
850nm VCSEL laser and PIN photodiode
Up to 70m for OM3-MMF and 100m for OM4-MMF transmission
Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle
Compatible with RoHS
Single +3.3V power supply
Real Time Digital Diagnostic Monitoring
Operating case temperature: -40 to 85°C
TX Power: 7.0~+2.4dBm
Receiver Sensitivity: < -10.3dBm
Powerbudget: 3dB
Application
25.78Gb/s single lane 100GE SR4
